1. Module Portfolio for International Markets
R&D Electronics offers TECHSEM thyristor diode modules to global customers, covering output currents from 20A to 2000A with reverse voltages from 600V to 6500V, including dual thyristor, diode, and bridge rectifier configurations.
Module Configurations
◆ Dual thyristor modules for AC control; Thyristor diode modules for mixed circuits; Diode modules for rectification; Fast thyristor fast recovery diode modules; Bridge rectifiers for complete solutions; Plate type power modules
International Application Fields
◆ Motor drives for industrial automation; Power supply systems; Power conversion equipment; Machinery manufacturing; Railway transportation systems; Welding machines; Renewable energy systems
Specifications Table
| Module Type | Current Range (A) | Voltage Range (V) | Key Applications |
|---|---|---|---|
| Dual Thyristor | 55-2000 | 600-6500 | AC control, motor drives |
| Thyristor Diode | 55-1000 | 600-1800 | Mixed circuits |
| Diode Module | 55-1500 | 600-2500 | Rectification |
| Fast Thyristor | 55-500 | 600-1800 | High frequency |
| Bridge Rectifier | 20-200 | 600-1800 | Complete solutions |
2. High Power Density 2000A Dual Thyristor
TECHSEM has launched 2000A dual thyristor modules offering the highest power density in the product range, now available to international markets through R&D Electronics.
2000A Module Features
◆ Highest power density in TECHSEM module range; 2000A dual thyristor configuration; 600-1800V voltage range; Advanced thermal management; Optimized package design; Industrial grade reliability
High Power Module Solutions
◆ MTx1000 at 1000A for heavy duty; MTx1200 at 1200A for large systems; MTx1500 at 1500A in 436F3 package; 2000A dual thyristor for maximum power; Comprehensive thermal resistance options; From 0.530 to 0.025 C/W
Specifications Table
3. International Standards and Compliance
TECHSEM thyristor diode modules meet international standards including IRIS for railway applications, ensuring acceptance in global markets with stringent quality requirements.
Quality Certifications
◆ IRIS certification for railway industry; ISO quality management system; CE marking for European compliance; UL recognition where applicable; IEC standard adherence; RoHS compliance
Testing and Validation
◆ High temperature blocking test; Ultrasonic microscopy inspection; Thermal cycling validation; Power cycling test; Mechanical vibration test; Surge current verification
Frequently Asked Questions
1：What is the current range of TECHSEM thyristor diode modules from R&D Electronics?
TECHSEM thyristor diode modules available from R&D Electronics cover output currents from 20A to 2000A, with the 2000A dual thyristor module offering the highest power density in the range.
2：What voltage range do TECHSEM thyristor diode modules support?
TECHSEM thyristor diode modules support reverse voltages from 600V to 6500V, covering a wide range of industrial and railway applications for international markets.
3：What international certifications do TECHSEM modules have?
TECHSEM modules carry IRIS certification for railway industry, CE marking for European compliance, UL recognition where applicable, IEC standard adherence, and RoHS compliance for global market acceptance.
4：Does R&D Electronics provide technical support for module selection?
Yes, R&D Electronics provides comprehensive technical support including module selection assistance, application engineering, thermal design guidance, circuit topology consultation, and quality documentation for international customers.
