| Part No | VRRM V | IC (A) | at TC (°C) | VCE (sat) @ TC =25°C (V) | Total Esw @ TC =150°C (mJ) | Rth(j-c) (per switch) (°C/kW) | Baseplate Dims (mm) | Buy |
|---|---|---|---|---|---|---|---|---|
| TG800FF08S1-S3A | 750V | 800 | 65 | 1.45 | 50 | 109 | 216*100 | Buy |
| TG600HF08M1-S3A | 750V | 600 | 65 | 1.5 | 76 | 90 | 152*62 | Buy |
| TG600FF08S3-S3A | 750V | 600 | 80 | 1.3 | 43.3 | 134 | 155*127 | Buy |
| TG400FF08S2-S3A | 750V | 400 | 65 | 1.65 | 22.8 | 200 | 140*112 | Buy |
| DIM2400ESM12-A | 1200V | 2400 | 85 | 2.2 | 800 | 6 | 190*140 | Buy |
| DIM1800ESM12-A | 1200V | 1800 | 85 | 2.2 | 570 | 8 | 190*140 | Buy |
| DIM1600FSM12-A | 1200V | 1600 | 85 | 2.2 | 500 | 9 | 140*130 | Buy |
| DIM1200FSM12-A | 1200V | 1200 | 85 | 2.2 | 500 | 9 | 140*130 | Buy |
| DIM800FSM12-A | 1200V | 800 | 85 | 2.2 | 400 | 12 | 140*130 | Buy |
| DIM800DDM12-A | 1200V | 800 | 85 | 2.2 | 280 | 18 | 140*130 | Buy |
| DIM800DCM12-A | 1200V | 800 | 85 | 2.2 | 280 | 18 | 140*130 | Buy |
| DIM600DDM12-A | 1200V | 600 | 85 | 2.2 | 200 | 24 | 140*130 | Buy |
| DIM400DDM12-A | 1200V | 400 | 85 | 2.2 | 120 | 36 | 140*130 | Buy |
| DIM2400ESS12-A | 1200V | 2400 | 85 | 2.2 | 800 | 6 | 140*190 | Buy |
| DIM1800ESS12-A | 1200V | 1800 | 85 | 2.2 | 570 | 8 | 140*190 | Buy |
| DIM1600FSS12-A | 1200V | 1600 | 85 | 2.2 | 500 | 9 | 140*130 | Buy |
| DIM1200FSS12-A | 1200V | 1200 | 85 | 2.2 | 400 | 12 | 140*130 | Buy |
| DIM800FSS12-A | 1200V | 800 | 85 | 2.2 | 280 | 18 | 140*130 | Buy |
| DIM800DCS12-A | 1200V | 800 | 85 | 2.2 | 280 | 18 | 140*130 | Buy |
| DIM800DDS12-A | 1200V | 800 | 85 | 2.2 | 280 | 18 | 140*130 | Buy |
| DIM600DDS12-A | 1200V | 600 | 85 | 2.2 | 200 | 24 | 140*130 | Buy |
| DIM400DDS12-A | 1200V | 400 | 85 | 2.2 | 120 | 36 | 140*130 | Buy |
| TG600HF12M1-S3A | 1200V | 600 | 85 | 1.7 | 139 | 49 | 152*62 | Buy |
| TG450HF12M1-S3A | 1200V | 450 | 95 | 1.65 | 78 | 52 | 152*62 | Buy |
| DIM2400ESM17-A | 1700V | 2400 | 75 | 2.7 | 1950 | 6 | 190*140 | Buy |
| DIM2400ESM17-PT500 | 1700V | 2400 | 118 | 1.8 | 1980 | 6 | 190*140 | Buy |
| DIM2400NSM17-PT500 | 1700V | 2400 | 85 | 2.1 | 1980 | 10 | 140*130 | Buy |
| DIM1600ECM17-A | 1700V | 1600 | 75 | 2.7 | 1250 | 9 | 190*140 | Buy |
| DIM1600FSM17-A | 1700V | 1600 | 75 | 2.7 | 1250 | 9 | 140*130 | Buy |
| DIM1600FSM17-PS500 | 1700V | 1600 | 80 | 2.3 | 1210 | 9 | 140*130 | Buy |
| DIM1200FSM17-A | 1700V | 1200 | 75 | 2.7 | 1000 | 12 | 140*130 | Buy |
| DIM1200DDM17-PT500 | 1700V | 1200 | 140 | 1.8 | 756 | 22 | 140*130 | Buy |
| DIM800FSM17-A | 1700V | 800 | 80 | 2.3 | 700 | 18 | 140*130 | Buy |
| DIM800DDM17-A | 1700V | 800 | 75 | 2.7 | 700 | 18 | 140*130 | Buy |
| DIM800DDM17-PS500 | 1700V | 800 | 80 | 2.3 | 520 | 18 | 140*130 | Buy |
| DIM800DCM17-A | 1700V | 800 | 75 | 2.7 | 785 | 18 | 140*130 | Buy |
| DIM600DDM17-A | 1700V | 600 | 75 | 2.7 | 620 | 24 | 140*130 | Buy |
| DIM600DCM17-A | 1700V | 600 | 75 | 2.7 | 620 | 24 | 140*130 | Buy |
| DIM400DDM17-A | 1700V | 400 | 75 | 2.7 | 350 | 36 | 140*130 | Buy |
| DIM400DCM17-A | 1700V | 400 | 75 | 2.7 | 350 | 36 | 140*130 | Buy |
| DIM400PHM17-A | 1700V | 400 | 75 | 2.7 | 350 | 36 | 140*73 | Buy |
| DIM400PBM17-A | 1700V | 400 | 75 | 4.9 | 350 | 36 | 140*73 | Buy |
| TIM2400ESM17-TSA | 1700V | 2400 | 100 | 1.75 | 2220 | 6 | 190*140 | Buy |
| TIM2400NSM17-TSA | 1700V | 2400 | 85 | 2.1 | 2220 | 10 | 140*130 | Buy |
| TIM1600FSM17-PSA | 1700V | 1600 | 80 | 2.3 | 1210 | 9 | 140*130 | Buy |
| TIM1200DDM17-TS000 | 1700V | 1200 | 75 | 1.8 | 788 | 22 | 140*130 | Buy |
| TG1000HF17H1-S300 | 1700V | 1000 | 85 | 1.85 | 745 | 20 | 250*89 | Buy |
| TIM800DDM17-TS000 | 1700V | 800 | 80 | 2.3 | 520 | 18 | 140*130 | Buy |
| TIM800DCM17-PSA | 1700V | 800 | 80 | 2.3 | 520 | 18 | 140*130 | Buy |
| TG650HF17H2-S3 | 1700V | 650 | 100 | 1.85 | 420 | 30 | 172*89 | Buy |
| DIM1500ESM33-MS | 3300V | 1500 | 120 | 2.2 | 8200 | 7 | 190*140 | Buy |
| DIM1500ESM33-TS | 3300V | 1500 | 110 | 2.2 | 6200 | 8 | 190*140 | Buy |
| DIM1500ASM33-TS001 | 3300V | 1500 | 110 | 2.2 | 6200 | 8 | 190*140 | Buy |
| DIM1500ESM33-TS001 | 3300V | 1500 | 110 | 2.2 | 5750 | 8 | 190*140 | Buy |
| DIM1000NSM33-TS | 3300V | 1000 | 110 | 2.2 | 3850 | 12 | 140*130 | Buy |
| DIM1000XSM33-TS001 | 3300V | 1000 | 110 | 2.2 | 3850 | 12 | 140*130 | Buy |
| DIM1000ECM33-TS | 3300V | 1000 | 110 | 2.2 | 3850 | 12 | 190*140 | Buy |
| DIM1000ACM33-TS001 | 3300V | 1000 | 110 | 2.2 | 4300 | 12 | 190*140 | Buy |
| DIM500GDM33-TS | 3300V | 500 | 110 | 2.2 | 2100 | 24 | 140*130 | Buy |
| DIM500GCM33-TS | 3300V | 500 | 110 | 2.2 | 2100 | 24 | 140*130 | Buy |
| DIM250PKM33-TS | 3300V | 250 | 110 | 2.2 | 1040 | 48 | 140*73 | Buy |
| DIM250PLM33-TS | 3300V | 250 | 110 | 2.2 | 1040 | 48 | 140*73 | Buy |
| DIM250PHM33-TS | 3300V | 250 | 110 | 2.2 | 1040 | 48 | 140*73 | Buy |
| DIM125PHM33-TS | 3300V | 125 | 110 | 2.2 | 480 | 96 | 140*73 | Buy |
| DIM1500ESM33-ML | 3300V | 1500 | 120 | 2 | 7350 | 7 | 190*140 | Buy |
| DIM1500ESM33-TL | 3300V | 1500 | 115 | 2 | 7800 | 8 | 190*140 | Buy |
| DIM1500ESM33-PS500 | 3300V | 1500 | 110 | 2.1 | 6010 | 8 | 190*140 | Buy |
| DIM1500ASM33-TL001 | 3300V | 1500 | 115 | 2 | 7800 | 8 | 190*140 | Buy |
| DIM1000NSM33-TL | 3300V | 1000 | 115 | 2 | 4840 | 12 | 140*130 | Buy |
| DIM1000XSM33-TL001 | 3300V | 1000 | 115 | 2 | 4840 | 12 | 140*130 | Buy |
| DIM1000ECM33-TL | 3300V | 1000 | 115 | 2 | 4840 | 12 | 190*140 | Buy |
| DIM1000ACM33-TL001 | 3300V | 1000 | 115 | 2 | 4840 | 12 | 190*140 | Buy |
| DIM500GDM33-TL | 3300V | 500 | 115 | 2 | 4840 | 12 | 190*140 | Buy |
| DIM500GCM33-TL | 3300V | 500 | 115 | 2 | 2650 | 24 | 140*130 | Buy |
| DIM250PKM33-TL | 3300V | 250 | 115 | 2 | 1300 | 48 | 140*73 | Buy |
| DIM250PLM33-TL | 3300V | 250 | 115 | 2 | 1300 | 48 | 140*73 | Buy |
| DIM250PHM33-TL | 3300V | 250 | 115 | 2 | 1300 | 48 | 140*73 | Buy |
| DIM125PHM33-TL | 3300V | 125 | 115 | 2 | 600 | 96 | 140*73 | Buy |
| DIM1500ESM33-MF | 3300V | 1500 | 108 | 2.3 | 3950 | 7 | 190*140 | Buy |
| DIM1500ESM33-PR500 | 3300V | 1500 | 110 | 2.4 | 4850 | 8 | 190*140 | Buy |
| DIM1200ASM33-F | 3300V | 1200 | 90 | 2.8 | 4400 | 8 | 190*140 | Buy |
| DIM1200ESM33-F | 3300V | 1200 | 90 | 2.8 | 4400 | 8 | 190*140 | Buy |
| DIM800NSM33-F | 3300V | 800 | 90 | 2.8 | 2950 | 12 | 140*130 | Buy |
| DIM800XSM33-F | 3300V | 800 | 90 | 2.8 | 2950 | 12 | 140*130 | Buy |
| DIM800ECM33-F | 3300V | 800 | 90 | 2.8 | 2950 | 12 | 190*140 | Buy |
| DIM500GDM33-PS500 | 3300V | 500 | 110 | 2.4 | 1780 | 24 | 160*130 | Buy |
| DIM400NSM33-F | 3300V | 400 | 90 | 2.8 | 1470 | 24 | 140*130 | Buy |
| DIM400GDM33-F | 3300V | 400 | 90 | 2.8 | 1470 | 24 | 160*130 | Buy |
| DIM400GCM33-F | 3300V | 400 | 90 | 2.8 | 1470 | 24 | 160*130 | Buy |
| DIM400XCM33-F | 3300V | 400 | 90 | 2.8 | 1470 | 24 | 140*130 | Buy |
| DIM200PLM33-F | 3300V | 200 | 90 | 2.8 | 655 | 48 | 140*73 | Buy |
| DIM200PKM33-F | 3300V | 200 | 90 | 2.8 | 655 | 48 | 140*73 | Buy |
| DIM200PHM33-F | 3300V | 200 | 90 | 2.8 | 655 | 48 | 140*73 | Buy |
| DIM100PHM33-F | 3300V | 100 | 90 | 2.8 | 335 | 96 | 140*73 | Buy |
| DIM1200ASM45-TS | 4500V | 1200 | 90 | 2.7 | 11100 | 8 | 190*140 | Buy |
| DIM1200ASM45-TS001 | 4500V | 1200 | 90 | 2.7 | 11100 | 8 | 190*140 | Buy |
| DIM800ACM45-TS | 4500V | 800 | 90 | 2.7 | 7400 | 12 | 190*140 | Buy |
| DIM800ACM45-TS001 | 4500V | 800 | 90 | 2.7 | 7400 | 12 | 190*140 | Buy |
| DIM800XSM45-TS | 4500V | 800 | 90 | 2.7 | 7400 | 12 | 140*130 | Buy |
| DIM800XSM45-TS001 | 4500V | 800 | 90 | 2.7 | 7400 | 12 | 140*130 | Buy |
| DIM400XCM45-TS | 4500V | 400 | 90 | 2.7 | 3800 | 24 | 140*130 | Buy |
| DIM400XCM45-TS001 | 4500V | 400 | 90 | 2.7 | 3800 | 24 | 140*130 | Buy |
| DIM400XSM45-TS | 4500V | 400 | 90 | 2.7 | 3800 | 24 | 140*130 | Buy |
| DIM400XSM45-TS001 | 4500V | 400 | 90 | 2.7 | 3800 | 24 | 140*130 | Buy |
| DIM1200ASM45-TL | 4500V | 1200 | 90 | 2.3 | 13650 | 8 | 190*140 | Buy |
| DIM1200ASM45-TL001 | 4500V | 1200 | 90 | 2.3 | 13650 | 8 | 190*140 | Buy |
| DIM800XSM45-TL | 4500V | 800 | 90 | 2.3 | 9100 | 12 | 140*130 | Buy |
| DIM800XSM45-TL001 | 4500V | 800 | 90 | 2.3 | 9100 | 12 | 140*130 | Buy |
| DIM1500ASM45-UF Trench Gate | 4500V | 1500 | 90 | 3.2 | 11100 | 8 | 190*140 | Buy |
| DIM1200ASM45-TF | 4500V | 1200 | 90 | 3.5 | 11100 | 8 | 190*140 | Buy |
| DIM1200ASM45-TF001 | 4500V | 1200 | 90 | 3.5 | 8950 | 8 | 190*140 | Buy |
| DIM750ASM65-TS000 | 6500V | 750 | 90 | 3 | 10300 | 9 | 190*140 | Buy |
| DIM500XSM65-TS | 6500V | 500 | 90 | 3 | 7000 | 12 | approximately 140*130 | Buy |
| DIM500ACM65-TS | 6500V | 500 | 90 | 3 | 7000 | 12 | approximately 190*140 | Buy |
| DIM250XCM65-TS000 | 6500V | 250 | 90 | 3 | 3500 | 24 | approximately 140*130 | Buy |
| DIM750ASM65-TL000 | 6500V | 750 | 100 | 2.5 | 16200 | 9 | approximately 190*140 | Buy |
| DIM1000ASM65-UF | 6500V | 1000 | 90 | 3.2 | 13800 | 8 | approximately 190*140 | Buy |
| DIM750ASM65-TF | 6500V | 750 | 90 | 3.2 | 10200 | 9 | approximately 190*140 | Buy |
| DIM750ASM65-PS500 | 6500V | 750 | 115 | 3 | 10200 | 9 | approximately 190*140 | Buy |
| DIM500XSM65-TF000 | 6500V | 500 | 95 | 3.6 | 5900 | 13.5 | approximately 130*140 | Buy |
