High voltage three-phase brushless motor drive for civilian and industrial use. Air conditioning fan motors with a high market share can provide drive control for various motors such as refrigerators, air conditioning compressor motors, and washing machine main motors. It can also correspond to the application of FOC sensorless vector control method.
| Part | Packaging | Built-in freewheeling diode | VCES (V) | IC (A) | PD (W) | VCE(SAT) (typ.) (V) | VCE(SAT) (max.) (V) | Buy |
|---|---|---|---|---|---|---|---|---|
| DGU4015G | TO252-2L | 400 | 15 | 60 | 1.1 | 1.4 | Buy | |
| DGU4020GR | TO252-2L | NO | 400 | 20 | 172 | 1.1 | 1.32 | Buy |
| DGU4520GR | TO252-2L | NO | 450 | 20 | 172 | 1.1 | 1.32 | Buy |
| DGU5020GR | TO252-2L | NO | 500 | 20 | 172 | 1.15 | 1.4 | Buy |
| FGM622S | TO3PF-3L | NO | 600 | 16 | 60 | 1.7 | 1.9 | Buy |
| FGM623S | TO3PF-3L | NO | 600 | 18 | 60 | 1.5 | 1.7 | Buy |
| MGD623N | TO3P-3L | YES | 600 | 37 | 150 | 1.7 | 2.3 | Buy |
| MGD623S | TO3P-3L | YES | 600 | 37 | 150 | 1.8 | 2.4 | Buy |
| Part | Packaging | Output (V) | Output (A) | RDS(ON) max./ VCE(SAT) typ. | Threshold (V) | Overcurrent (OCP or OCL) | Buy |
|---|---|---|---|---|---|---|---|
| SAM212M05BF1 | DIP30 | 1200 | 5 | 1.30 V | 3.3/5.0 | OCP | Buy |
| SAM212M10BF1 | DIP30 | 1200 | 10 | 1.6 V | 3.3/5.0 | OCP | Buy |
| SAM265M50BS3 | DIP30 | 650 | 50 | 1.7 | 3.3/5.0 | OCP | Buy |
| SCM1242MA | DIP33 | 600 | 15 | 1.70V | 3.3/5.0 | OCP | Buy |
| SCM1242MF | DIP33 | 600 | 15 | 1.70V | 3.3/5.0 | OCP | Buy |
| SCM1256MF | DIP33 | 600 | 30 | 1.70V | 3.3/5.0 | OCP | Buy |
| SCM1261MF | DIP33 | 600 | 10 | 1.70V | 3.3/5.0 | OCP | Buy |
| SCM1263MF | DIP33 | 600 | 15 | 1.70V | 3.3/5.0 | OCP | Buy |
| SCM1265MF | DIP33 | 600 | 20 | 1.70V | 3.3/5.0 | OCP | Buy |
| SCM1272MA | DIP33 | 600 | 15 | 1.70V | 3.3/5.0 | OCP | Buy |
| SCM1272MF | DIP33 | 600 | 15 | 1.70V | 3.3/5.0 | OCP | Buy |
| SCM1274MF | DIP33 | 600 | 20 | 1.70V | 3.3/5.0 | OCP | Buy |
| SCM1276MF | DIP33 | 600 | 30 | 1.70V | 3.3/5.0 | OCP | Buy |
| SCM2007MKF | DIP33 | 600 | 20 | 1.70V | 3.3 / 5.0 | OCP | Buy |
| SCM2008MKF | DIP33 | 600 | 30 | 1.70V | 3.3 / 5.0 | OCP | Buy |
| SIM2-151A | DIP40 | 600 | 15 | 1.6 V | 3.3/5.0 | OCP | Buy |
| SIM2-151AB | DIP40 | 600 | 15 | 1.6 V | 3.3/5.0 | OCP | Buy |
| SIM2602M | DIP40 | 600 | 5 | ― | OCP | Buy | |
| SIM6891MD | DIP40 | 600 | 2.5 | 2.5 | 3.3/5.0 | OCP | Buy |
| SIM6891MDN | DIP40 | 600 | 2.5 | 2.5 | 3.3/5.0 | OCP | Buy |
| SIM6892M | DIP40 | 600 | 5 | 1.75 | 3.3/5.0 | OCP | Buy |
| SIM6893M | DIP40 | 600 | 5 | 0.6 | 3.3/5.0 | OCP | Buy |
| SIM6895M | DIP40 | 600 | 5 | 1.75 | 3.3/5.0 | OCP | Buy |
| SIM6896M | DIP40 | 600 | 3 | 1.85 | 3.3/5.0 | OCP | Buy |
| SLA6805MH | ZIP23 (with radiator) | 600 | 3 | 1.75V | 3.3/5.0 | OCP | Buy |
| SLA6826MH | ZIP24 (with radiator) | 250 | 2 | 1.5Ω | 3.3/5.0 | 无 | Buy |
| SLA6846MH | ZIP24 (with radiator) | 600 | 5 | 1.75V | 3.3/5.0 | 无 | Buy |
| SLA6868MH | ZIP24 (with radiator) | 500 | 2.5 | 2.4Ω | 5 | OCP/OCL | Buy |
| SLA6870MH | ZIP24 (with radiator) | 500 | 3 | 1.7Ω | 5 | OCP/OCL | Buy |
| SMA6821MH | ZIP24 | 250 | 2 | 1.5Ω | 3.3/5.0 | 无 | Buy |
| SX68127MA | SOP36 | 600 | 2 | 2.5Ω | ― | OCP/OCL | Buy |
| SX68128MA | SOP36 | 600 | 1.5 | 3.6Ω | ― | OCP/OCL | Buy |
| SX68128MB | SOP36 | 600 | 1.5 | 3.6Ω | ― | OCP/OCL | Buy |
| SX68201M | SOP36 | 250 | 2 | 1.25Ω | ― | SOCP/HOCP | Buy |
| SX68204M | SOP36 | 600 | 1.5 | 2.9Ω | ― | SOCP/HOCP | Buy |
| SX68205M | SOP36 | 600 | 2 | 2.0Ω | ― | SOCP/HOCP | Buy |
| Part | Packaging | VDS (V) | VGSS (V) | ID (－) (A) | ID (＋) (A) | PD (W) | VTH (min.) (V) | VTH (max.) (V) | Buy |
|---|---|---|---|---|---|---|---|---|---|
| 2SK2420 | TO220F-3L | 60 | ±20 | -30 | 30 | 40 | 2 | 4 | Buy |
| 2SK2701A | TO220F-3L | 450 | ±30 | -7 | 7 | 35 | 2 | 4 | Buy |
| 2SK2943 | TO220F-3L | 900 | ±30 | -3 | 3 | 30 | 2 | 4 | Buy |
| 2SK3003 | TO220F-3L | 200 | ±20 | -18 | 18 | 35 | 2 | 4 | Buy |
| 2SK3004 | TO220F-3L | 250 | ±20 | -18 | 18 | 35 | 2 | 4 | Buy |
| 2SK3199 | TO220F-3L | 500 | ±30 | -5 | 5 | 30 | 2 | 4 | Buy |
| 2SK3711 | TO3P-3L | 60 | ±20 | -70 | 70 | 130 | 2 | 4 | Buy |
| 2SK3801 | TO3P-3L | 40 | ±20 | -70 | 70 | 100 | 2 | 4 | Buy |
| 2SK4161D | TO3P-3L | 60 | ±20 | 100 | 132 | 3.2 | 4 | Buy | |
| DJR0417 | TO252-2L | -40 | -15, +0 | -17 | 48 | -1 | -2.5 | Buy | |
| DKG1020 | TO252-2L | 100 | ±20 | -20 | 20 | 40 | 1.5 | 2.5 | Buy |
| FKP202 | TO220F-3L | 200 | ±30 | -45 | 45 | 40 | 3 | 4.5 | Buy |
| FKP250A | TO3PF-3L | 250 | ±30 | -50 | 50 | 85 | 3 | 4.5 | Buy |
| FKP252 | TO220F-3L | 250 | ±30 | -25 | 25 | 40 | 3 | 4.5 | Buy |
| FKP253 | TO220F-3L | 250 | ±30 | -20 | 20 | 40 | 3 | 4.5 | Buy |
| FKV550N | TO220F-3L | 50 | ±20 | 50 | 35 | 3 | 4.2 | Buy | |
| FKV575 | TO220F-3L | 50 | ±20 | -75 | 75 | 40 | 3 | 4.5 | Buy |
| FLD470 | TO220F-3L | 40 | ±20 | -70 | 70 | 35 | 2 | 4 | Buy |
| MLD685D | TO3P-3L | 60 | ±20 | -85 | 85 | 150 | 2 | 3 | Buy |
| SUK3015 | TO220S-2L | 300 | ±20 | -15 | 15 | 89 | 1.5 | 2.5 | Buy |
| Part | Packaging | VCBO (V) | VCEO (V) | IC (－) (A) | IC (＋) (A) | PC (W) | hFE (min.) | Buy |
|---|---|---|---|---|---|---|---|---|
| 2SA1294 | TO3P-3L | -230 | -230 | -15 | 130 | 50 | Buy | |
| 2SA1303 | TO3P-3L | -150 | -150 | -14 | 125 | 50 | Buy | |
| 2SA1386 | TO3P-3L | -160 | -160 | -15 | 130 | 50 | Buy | |
| 2SA1386A | TO3P-3L | -180 | -180 | -15 | 130 | 50 | Buy | |
| 2SA1488 | TO220F-3L | -60 | -60 | -4 | 25 | 40 | Buy | |
| 2SA1488A | TO220F-3L | -80 | -80 | -4 | 25 | 40 | Buy | |
| 2SA1492 | TO3P-3L | -180 | -180 | -15 | 130 | 50 | Buy | |
| 2SA1567 | TO220F-3L | -50 | -50 | -12 | 35 | 50 | Buy | |
| 2SA1667 | TO220F-3L | -150 | -150 | -2 | 25 | 60 | Buy | |
| 2SA1668 | TO220F-3L | -200 | -200 | -2 | 25 | 60 | Buy | |
| 2SA1673 | TO3PF-3L | -180 | -180 | -15 | 85 | 50 | Buy | |
| 2SA1693 | TO3P-3L | -80 | -80 | -6 | 60 | 50 | Buy | |
| 2SA1694 | TO3P-3L | -120 | -120 | -8 | 80 | 50 | Buy | |
| 2SA1695 | TO3P-3L | -140 | -140 | -10 | 100 | 50 | Buy | |
| 2SA1725 | TO220F-3L | -80 | -80 | -6 | 30 | 50 | Buy | |
| 2SA1746 | TO3PF-3L | -70 | -50 | -12 | 60 | 50 | Buy | |
| 2SA1907 | TO3PF-3L | -80 | -80 | -6 | 60 | 50 | Buy | |
| 2SA1908 | TO3PF-3L | -120 | -120 | -8 | 75 | 50 | Buy | |
| 2SA1909 | TO3PF-3L | -140 | -140 | -10 | 80 | 50 | Buy | |
| 2SB1257 | TO220F-3L | -60 | -60 | -4 | 25 | 2000 | Buy | |
| 2SB1259 | TO220F-3L | -120 | -120 | -10 | 30 | 2000 | Buy | |
| 2SB1559 | TO3P-3L | -160 | -150 | -8 | 80 | 5000 | Buy | |
| 2SB1560 | TO3P-3L | -160 | -150 | -10 | 100 | 5000 | Buy | |
| 2SB1587 | TO3PF-3L | -160 | -150 | -8 | 75 | 5000 | Buy | |
| 2SB1588 | TO3PF-3L | -160 | -150 | -10 | 80 | 5000 | Buy | |
| 2SB1647 | TO3P-3L | -150 | -150 | -15 | 130 | 5000 | Buy | |
| 2SB1649 | TO3PF-3L | -150 | -150 | -15 | 85 | 5000 | Buy | |
| 2SC3263 | TO3P-3L | 230 | 230 | 15 | 130 | 50 | Buy | |
| 2SC3284 | TO3P-3L | 150 | 150 | 14 | 125 | 50 | Buy | |
| 2SC3519 | TO3P-3L | 160 | 160 | 15 | 130 | 50 | Buy | |
| 2SC3519A | TO3P-3L | 180 | 180 | 15 | 130 | 50 | Buy | |
| 2SC3835 | TO3P-3L | 200 | 120 | 7 | 70 | 70 | Buy | |
| 2SC3851 | TO220F-3L | 80 | 60 | 4 | 25 | 40 | Buy | |
| 2SC3851A | TO220F-3L | 100 | 80 | 4 | 25 | 40 | Buy | |
| 2SC3852 | TO220F-3L | 80 | 60 | 3 | 25 | 500 | Buy | |
| 2SC3852A | TO220F-3L | 100 | 80 | 3 | 25 | 500 | Buy | |
| 2SC3856 | TO3P-3L | 200 | 180 | 15 | 130 | 80 | Buy | |
| 2SC4024 | TO220F-3L | 100 | 50 | 10 | 35 | 300 | Buy | |
| 2SC4131 | TO3PF-3L | 100 | 50 | 15 | 60 | 60 | Buy | |
| 2SC4153 | TO220F-3L | 200 | 120 | 7 | 30 | 70 | Buy | |
| 2SC4304 | TO220F-3L | 900 | 800 | 3 | 35 | 10 | Buy | |
| 2SC4381 | TO220F-3L | 150 | 150 | 2 | 25 | 60 | Buy | |
| 2SC4382 | TO220F-3L | 200 | 200 | 2 | 25 | 60 | Buy | |
| 2SC4388 | TO3PF-3L | 200 | 180 | 15 | 85 | 50 | Buy | |
| 2SC4445 | TO3PF-3L | 900 | 800 | 3 | 60 | 10 | Buy | |
| 2SC4466 | TO3P-3L | 120 | 80 | 6 | 60 | 50 | Buy | |
| 2SC4467 | TO3P-3L | 160 | 120 | 8 | 80 | 50 | Buy | |
| 2SC4468 | TO3P-3L | 200 | 140 | 10 | 100 | 50 | Buy | |
| 2SC4511 | TO220F-3L | 120 | 80 | 6 | 30 | 50 | Buy | |
| 2SC5099 | TO3PF-3L | 120 | 80 | 6 | 60 | 50 | Buy | |
| 2SC5100 | TO3PF-3L | 160 | 120 | 8 | 75 | 50 | Buy | |
| 2SC5101 | TO3PF-3L | 200 | 140 | 10 | 80 | 50 | Buy | |
| 2SD2014 | TO220F-3L | 120 | 80 | 4 | 25 | 2000 | Buy | |
| 2SD2015 | TO220F-3L | 150 | 120 | 4 | 25 | 2000 | Buy | |
| 2SD2016 | TO220F-3L | 200 | 200 | 3 | 25 | 1000 | Buy | |
| 2SD2017 | TO220F-3L | 300 | 250 | 6 | 35 | 2000 | Buy | |
| 2SD2141 | TO220F-3L | 380 | 380 | 6 | 35 | 1500 | Buy | |
| 2SD2390 | TO3P-3L | 160 | 150 | 10 | 100 | 5000 | Buy | |
| 2SD2439 | TO3PF-3L | 160 | 150 | 10 | 80 | 5000 | Buy | |
| 2SD2560 | TO3P-3L | 150 | 150 | 15 | 130 | 5000 | Buy | |
| 2SD2562 | TO3PF-3L | 150 | 150 | 15 | 85 | 5000 | Buy | |
| 2SD2633 | TO220F-3L | 200 | 150 | 8 | 35 | 2000 | Buy | |
| MN1526 | TO3P-3L | 260 | 260 | 15 | 150 | 40 | Buy | |
| MP1526 | TO3P-3L | -260 | -260 | -15 | 150 | 40 | Buy |
| Part | Packaging | Number of circuits | VCEO/VDSS/VCES (＋) (V) | IC/ID (－) (A) | IC/ID (＋) (A) | IC(PULSE)/ID(PULSE) (A) | hFE (min.) | RDS(ON) (max.) (Ω) | Buy |
|---|---|---|---|---|---|---|---|---|---|
| SLA4030 | SIP12 (with radiator) | 4 | 100 | 4 | 2000 | Buy | |||
| SLA4031 | SIP12 (with radiator) | 4 | 120 | 4 | 2000 | Buy | |||
| SLA4036 | ZIP15 (with radiator) | 6 | 120 | 2 | 4 | 2000 | Buy | ||
| SLA4051 | ZIP21 (with radiator) | 9 | 120 | 2 | 4 | 2000 | Buy | ||
| SLA4052 | ZIP21 (with radiator) | 9 | 120 | 3 | 5 | 2000 | Buy | ||
| SLA5037 | SIP12 (with radiator) | 4 | 100 | 10 | 0.08 | Buy | |||
| SLA5041 | SIP12 (with radiator) | 4 | 200 | 10 | 0.18 | Buy | |||
| SLA5059 | SIP12 (with radiator) | 6 | 60 | -4 | 4 | 0.55 | Buy | ||
| SLA5060 | SIP12 (with radiator) | 6 | 60 | -6 | 6 | 0.22 | Buy | ||
| SLA5061 | SIP12 (with radiator) | 6 | 60 | -10 | 10 | 0.14 | Buy | ||
| SLA5064 | SIP12 (with radiator) | 6 | 60 | -10 | 10 | 0.14 | Buy | ||
| SLA5065 | ZIP15 (with radiator) | 4 | 60 | 7 | 0.1 | Buy | |||
| SLA5068 | ZIP15 (with radiator) | 6 | 60 | 7 | 0.1 | Buy | |||
| SLA5073 | ZIP15 (with radiator) | 6 | 60 | 5 | 0.3 | Buy | |||
| SLA5074 | ZIP15 (with radiator) | 4 | 60 | 5 | 0.3 | Buy | |||
| SLA5075 | ZIP15 (with radiator) | 6 | 500 | -5 | 5 | 1.4 | Buy | ||
| SLA5085 | SIP12 (with radiator) | 5 | 60 | 5 | 0.22 | Buy | |||
| SLA5086 | SIP12 (with radiator) | 5 | 0.22 | Buy | |||||
| SLA5096 | ZIP15 (with radiator) | 6 | 55 | -8 | 8 | 0.08 | Buy | ||
| SLA5201 | ZIP15 (with radiator) | 6 | 600 | 7 | Buy | ||||
| SLA5212 | ZIP15 (with radiator) | 6 | 35 | -8 | 8 | 0.07 | Buy | ||
| SLA5222 | SIP7 | 4 | 600 | 30 | 100 | Buy | |||
| SLA5227 | SIP6 | 4 | 600 | 30 | Buy | ||||
| SMA4020 | SIP12 | 4 | 2000 | Buy | |||||
| SMA4030 | SIP12 | 4 | 100 | 3 | 2000 | Buy | |||
| SMA4032 | SIP12 | 4 | 100 | 3 | 2000 | Buy | |||
| SMA4033 | SIP12 | 4 | 100 | 2 | 2000 | Buy | |||
| SMA4036 | ZIP15 | 6 | 120 | 2 | 2000 | Buy | |||
| SMA4038 | ZIP15 | 6 | 120 | 3 | 5 | 2000 | Buy | ||
| SMA5106 | SIP12 | 4 | 100 | 4 | 0.55 | Buy | |||
| SMA5112 | SIP12 | 6 | 250 | 7 | 0.5 | Buy | |||
| SMA5117 | SIP12 | 6 | 250 | 7 | 0.25 | Buy | |||
| SMA5118 | SIP12 | 6 | 500 | -5 | 5 | 1.4 | Buy | ||
| SMA5125 | SIP12 | 6 | 60 | -10 | 10 | 0.14 | Buy | ||
| SMA5127 | SIP12 | 6 | 60 | -4 | 4 | 0.55 | Buy | ||
| SMA5130 | ZIP15 | 6 | 250 | -2.5 | 2.5 | 2000 | 0.9 | Buy | |
| SMA5131 | SIP12 | 6 | 250 | 2 | 1.8 | Buy | |||
| SMA5132 | SIP12 | 6 | 500 | 1.5 | 4 | Buy | |||
| SMA5133 | SIP12 | 6 | 500 | 2.5 | 2 | Buy | |||
| SMA5135 | SIP12 | 6 | 60 | -6 | 6 | ± 10 | 0.22 | Buy | |
| SMA5145 | SIP12 | 6 | 500 | 1.5 | 3 | 4 | Buy | ||
| SMA5146 | SIP12 | 6 | 500 | 2.5 | 5 | 2.4 | Buy | ||
| SMA6010 | SIP12 | 6 | 60 | -4 | 4 | 2000 | Buy | ||
| STA302A | SIP8 | 3 | 1000 | Buy | |||||
| STA303A | SIP8 | 3 | 100 | 4 | 100 | Buy | |||
| STA402A | SIP10 | 4 | 1000 | Buy | |||||
| STA403A | SIP10 | 4 | 100 | 4 | 1000 | Buy | |||
| STA404A | SIP10 | 4 | 200 | 3 | 1000 | Buy | |||
| STA406A | SIP10 | 4 | 60 | 6 | 2000 | Buy | |||
| STA412A | SIP10 | 4 | 60 | 3 | 300 | Buy | |||
| STA434A | SIP10 | 4 | 60 | -4 | 4 | 1000 | Buy | ||
| STA457C | SIP10 | 4 | 60 | -4 | 4 | 2000 | Buy | ||
| STA473A | SIP10 | 4 | 100 | 2 | 2000 | Buy |
